Special cable for correct communication between Pylontech Lithium batteries and Voltronic VMIII, VM IV and MAX inverters. 2.5 meters long with RJ45 at both ends, to connect to the ION-LI port of the Axpert VMIII inverter on one end, and to the RS485 port on the Pylontech battery on the other.
Voltronic Axpert KING 24/3000 MPPT 60A CanBus
Voltronic Hybrid Inverter Axpert VM III 24V 3000W with 60A MPPT.
This inverter is Voltronics' most advanced model. Bluetooth connectable with the mobile app. This new device allows full configuration of equalization and absortion times and voltages to optimally charge the batteries. It incorporates a 0 mS transfer relay and can automatically start a generator. CanBus port, prepared and calibrated for Pylontech Lithium batteries. Load statistics as daily and total consumption are recorded with the possibility of downloading data via USB.
100% secure site with SSL certificate and committed to Confianza Online.
Delivery time: 1 to 4 weekdays for products in stock once the payment is received by wire transfer, Paypal or credit card.
Voltronic presents this new product. The Axpert KING inverter / Charger / Regulator. An extremely high efficiency pure sinewave inverter with Power Factor 1
THIS PRODUCT IS THE TOTAL SOLUTION for self supplying electricity.
The Axpert KING is presented with a supercompact renovated design and a more complete display and menu. Among the improvements we highlight: 4
- Possibility of programming the absorption times. In addition to the equalization we can also regulate the equalization time.
- Bluetooth: Through the free app that can be downloaded from Google Play, we can access system information and monitor it from home.
- BMS Port: Reserved for future firmware updates of the device
- 0ms transfer relay: The transfer relay has been improved and the jump is already negligible. With 0 ms, the most delicate devices are not affected by the change of the inverter mode> bypass and vice versa in case the batteries are depleted / recharged.
- 60 A battery charger: allows you to use the source of a generator or electrical network to recharge the battery in a few hours on days of bad weather.
- Removable screen with new data: From the new screen we can monitor the system completely, seeing in detail the status, load, voltages and production statistics, as well as photovoltaic production in real time of what is happening in this inverter and once you understand the display, its very intuitive to use.
The Voltonic Axpert KING inverters come with a 2 year warranty.
Power: 3000VA / 3000W (Power Factor 1)
Voltage in: 230 VAC with Selectable Voltage Range: 170-280V / 90-280V
Working frequency: 50 Hz / 60 Hz (Automatic detection)
Output: AC Output Voltage (Batt. Mode): 230V
Peak power: 6000VA
Efficiency: 90% to 93% Pure Sinusoidal Wave
Baterias: Voltage: 24VDC
Solar Regulator: Solar MPPT type regulator (maximum power point tracking)
Maximum photovoltaic power: 1500W MPPT
Solar array Voltage Range: 35-110VDC
Maximum open circuit voltage: 145VDC Maximum current: 60A
Warranty: National, 2 years
