Vctron SmartSolar MPPT 75/15
The Victron SmartSolar 75/15 charge controller charger gathers energy from your solar panels, and stores it in your batteries.
Using the latest, fastest technology, SmartSolar maximises this energy-harvest, driving it intelligently to achieve full charge in the shortest possible time. The SmartSolar maintains battery health, extending its life.
Site 100% secured by means of SSL certificate and business adhered to Confianza Online.
Delivery time from 1 (MRW) to 5 (Rhenus) working days for products in stock or from receipt of payment by bank transfer, Paypal and credit card.
SmartSolar 75/10 - Ultra-fast Maximum Power Point Tracking
The Victron SmartSolar 75/10 MPPT optimizes battery charging by constantly monitoring the voltage and current output of your solar (PV) panels, MPPT technology ensures that every drop of available power is rinsed out of your panels, and harvested for storage. The advantage of this is most noticeable when the sky is partially clouded, and light intensity is constantly changing.
Remote Monitoring and Control
Remotely control and monitor the extensive features of your SmartSolar MPPT charger by attaching a bluetooth dongle and pairing it with your smartphone or other device via VictronConnect. If your installation is connected to the internet Victron Remote Management Portal provides access to the full power of your MPPT, anytime, anywhere; both services are free to use. For remote installations - even when there is no internet connection or phone signal nearby - you may be able to monitor your MPPT by bluetooth-pairing with a (long-range wide area network) device, available optionally.
- Voltages: 12 y 24V (autodetect)
- Máximum charge current: 15A
- Max. solar array: 220W (12V) or 440W (24V)
- Máx. fv array VOC: 75V
- Max short circuit current: 15A
- Max Efficiency: 98%
- Selfconsumption: 30mA (12V)/20mA 24V
- Charging alogarithm: Adjustable: Multistep variable
- Temp compensation (ºC):-16mVºC (12V) / -32mVºC (24V)
- Protection: electronic short circuit/overtem
- Working temp: -30ºC hasta +60ºC. Full power upto 40ºC
- Max humidity: 95%
- Connections: 6mm2
- Size wxlxb: 100x113x40 mm
- Weight: 0,5kgs
Complies: EN/IEC 62109-1 / UL 1741 / CSA C22.2 NO.107.1-16
