Single phase SmartMeter Chint DDSU666 100A with 1x CT for SAJ Inverters

Chint DDSU666 100A Smart Meter with CT for SAJ Inverters

Monitoring Kit for SAJ Inverters: An advanced solution for tracking and measuring energy in singe phase power systems. It includes the Chint DDSU666 single-phase Wattmeter and an SEC device for data collection, providing a complete and accurate real-time monitoring system.

Key Features:

• Intelligent and programmable design: Allows real-time measurement of electrical parameters such as voltage, current, active and reactive power, frequency, power factor, and more.
• LCD display: Provides a clear and detailed visualization of monitored data.
• Advanced connectivity:
  • Communication via RS485, compatible with the DL/T645-2007 protocol and customizable for MODBUS-RTU.
  • Capable of collecting and transmitting data with high accuracy, ensuring reliable monitoring.
• Time-based scalability: Supports measurements in peak, high, flat, and low periods, optimizing energy consumption analysis.
• Practical and standard installation:
  • DIN rail mounting (DIN35mm).
  • Compatible with SAJ inverters, ensuring seamless and efficient integration.

Technical Specifications:

• Indirect measurement: Uses a current transformer (CT) to accurately record the consumption of each phase.
• High compatibility: Designed for residential, commercial, and industrial installations.
• Measured parameters: Voltage, current, frequency, active and reactive power, power factor, etc.

This is the ideal tool for obtaining detailed energy data and improving efficiency in photovoltaic installations orany singe phase power system. Its integration with SAJ inverters ensures optimal and comprehensive energy management.
